News

New Services

We introduce new services for our customers:

  • Avionics qualification test documentation:
  • Qualification Test Plan
  • EMI Qualification Test Procedures
  • Env Qualification Test Procedures
Electronic Design Service
Electronic Design Service

Upgrade

  • ARINC 429 / ARINC 717 Qualification Test Card (High Level EMI and Level 4 Lightning protection)
    EDS PN: 1012001002R
  • Discrete Ground Open Qualification Test Card (High Level EMI and Lightning protection) upgrade was completed
    EDS PN: 1012001001R02

Product Update Announcement

We Announce New Revision (R02) Of Ground Open Discrete Test Card For Avionics Qualification Testing

New Product Announcement

Avionics PCB Trace Width Lightning Calculator   is available on Calculators page.

Avionics Lightning Resistor Calculator   is available on Calculators page.

New Line Of Avionics Qualification/simulation/test Cards With Lightning And HIRF Protection:

EDS PN: 1012008001R - A429 / Discrete to USB / Ethernet / RS232 Adapter (Converter)

EDS PN: 1012009001R - A717 / Discrete to USB / Ethernet / RS232 Adapter (Converter)

EDS PN: 1012007001R - RS422 / RS232 / Discrete to USB / Ethernet Adapter (Converter)

RJ45 Eye Diagram Test Adapter
Avionics Ethernet Qualification Test Card (Quadrax / RJ45)
Quadrax Eye Diagram Test Adapter

EDS PN: 1022002001R
Test adapter application:

  • Avionics (A664 compliance) 100BASE TX Eye diagram testing
  • Avionics (A664 compliance) 1000BASE T Template, Peak Volt, Drop and Distortion testing
  • Other Hi Speed 100 ohms differential signal interfaces where Quadrax connector and terminations need to be used during testing
Discrete Ground Open Qualification Test Card (High Level EMI and Level 4 Lightning protection)
Avionics Voltage Open Discrete Qualification Test card

EDS PN: 1012006001R

New discrete cards have advanced design solution, which allows to use two different types of installation on the bulkhead - Flat and Edge installations.

Flat installation – test card is placed in parallel to bulkhead. This type of installation is used when it is enough room on the bulkhead for installation of supporting equipment (extremely good bonding).

Edge installation – test card is placed in perpendicular to bulkhead. Special bonding frame is used for mounting card. This type of installation is used when a lot of equipment need to be installed on the bulkhead (saved bulkhead room with very good bonding).
